Instagrid ONE - Instagrid

Instagrid ONE

Power all
in one

Rated output power

3.6 kW (16 A)

Peak power output

18 kW (80 A)

Rated energy capacity

2.1 kWh

Weight

20 kg

Electrical
Output voltage
230 V (AC) / 50 Hz
Rated power output
3.6 kW (16 A)
Rated energy capacity
2.1 kWh
Charge duration
< 3 h to 100%
On (idle)
150 h
Storage
> 3 years (switch in “off” or “transport” mode)
Output socket
EU CEE 7/3 Socket (16 A)
Output socket
Neutrik powerCON TRUE1 TOP®
Input charging socket
Neutrik powerCON TRUE1 TOP®
Physical
Weight
20 kg
Dimensions
420 x 210 x 420 mm
Outer case
Recycled aluminium
Electrical
Physical
Output voltage
230 V (AC) / 50 Hz
Weight
20 kg
Rated power output
3.6 kW (16 A)
Dimensions
420 x 210 x 420 mm
Rated energy capacity
2.1 kWh
Outer case
Recycled aluminium
Charge duration
< 3 h to 100%
On (idle)
150 h
Storage
> 3 years (switch in “off” or “transport” mode)
Output socket
EU CEE 7/3 Socket (16 A)
Output socket
Neutrik powerCON TRUE1 TOP®
Input charging socket
Neutrik powerCON TRUE1 TOP®
Peak power
150% overload (>500 sec)
5.4 kW (24 A)
200% overload (>50 sec)
7.2 kW (32 A)
250% overload (>10 sec)
9.0 kW (40 A)
Peak power
18.0 kW (80 A)
Environment
IP class
IP54
Noise emissions
< 10 dB(A)
Peak power
Environment
150% overload (>500 sec)
5.4 kW (24 A)
IP class
IP54
200% overload (>50 sec)
7.2 kW (32 A)
Noise emissions
< 10 dB(A)
250% overload (>10 sec)
9.0 kW (40 A)
Peak power
18.0 kW (80 A)
Icon

Power your most demanding tools

18 kW peak power

Work anywhere

Take a 230V wall socket with you – power any device no matter where you are.

Icon

Fast charging

Full charge in 3 hours. Charge Instagrid ONE in the middle of your workday.

Icon

Robust and weather-proof

IP44 rating. Work in any conditions, unaffected by dust or water.

Key Benefits


Better than mobile generators

With a rated power output of 3,600 W and a peak output of 18,000 W, Instagrid GO is significantly lighter and quieter than traditional combustion generators, all the while delivering superior performance.


Lightweight and robust

Instagrid GO weighs only 46 lb and can be carried in one hand. It’s passively cooled and contains no moving parts. It is IP 44 rated and is unaffected by dust or moisture.


Significant cost savings compared to generators

Our batteries are highly efficient and cost 80% less over their lifetime compared to combustion generators. Save money on fuel and avoid maintenance costs altogether.

Be the first to know

Whether you are in the construction, film & media, events, or emergency services sector, Instagrid LINK brings freedom to the way you work. Connect Instagrid LINK to Instagrid ONE to expand its features and enable new and powerful applications. Instagrid LINK will start shipping at the end of March. Register here to receive the latest updates about the launch. By subscribing, you acknowledge and consent to the receipt of marketing-related email communications from Instagrid, such as special offers and news. (We hate spam too, you can unsubscribe at any time).

background image
background image

Instagrid GO

Portable energy
reinvented

Advanced portable power supplies that break the mold. No more generators – just powerful, sustainable and reliable power on demand.
